Manley 594030C-8 4.6L / 5.4L Platinum Series Flat Top Pistons 3.582" Bore - AP Steel Rings Included

MAN-594030C-8
Limited Supply: only 1 remaining
Was: $1,068.98
Sale: $1,015.53
Save: 5%
Save: $53.45
Qty:
Free Shipping!

Description



  • 2618 High Strength Material, Lightweight Design
  • 1.2mm Offset Wrist Pin Location for Quiet Startups - Mimics OEM Design
  • Perfect Ring Groove to Skirt Squareness
  • Pressure Balance Groove
  • 2.500" Premium 4130 Chrome Moly Wrist Pins included with Round Wire Locks
  • Fully Banded Skirt Design for Increased Skirt Stability
  • 1.5mm x 1.5mm x 3mm Ring Stack
  • 9310 Alloy Wrist Pin upgrade available - Recommended for 800+ HP

Specifications

Part Number  594030C-8
Bore  3.582"
Dish Volume  Flat Top
Compression Height  1.220"
Stroke 3.543" / 4.165"
Rod Length  5.933" / 6.657"
Wrist Pin  .866" x 2.500"
Wrist Pin Material  4130 Chrome Moly / 9310 Tool Steel Available
Ring Stack  1.5mm x 1.5mm x 3mm
Piston Weight  350 grams



Compression Ratios



   2V PI 42cc   2V NPI 51cc   4V 52cc
 4.6L    12.85:1  11.02:1  10.85.1
 5.4L    11.13:1    9.95:1  9.83:1
