Modular Head Shop 1500+ HP 5.0L Coyote Rotating Assembly - Boss 302 Forged Crankshaft, Oliver Billet Rods and JE Ultra Pistons

MHS-500015C
Available in 10.0:1 and 11.0:1 Compression.
Pricing: $3,279.00

Customize Your Item

- Select Bore -
 * required
- Select Compression Ratio -
 * required
- Balance Rotating Assembly? -
 * required
Qty:
Free Shipping!

Description

  • FRPP Boss 302 Forged Crankshaft
  •  Oliver Billet Standard Light Connecting Rods with 7/16" ARP 2000 Bolts
  • JE ULTRA Pistons
    • Heavy Duty Strutted Forging
    • Lateral Gas Ports for better top ring seal
    • Ceramic Dome Thermal Barrier Coating JE
    • Perfect Skirt Coating
    • .230" Wall Tool Steel Wrist Pins
    • JE Pro Steel Piston Rings
      • ​Gas Nitrided Steel Top, Napier 2nd, 3 Piece Oil
  • Clevite H-Series Main Bearings
  • Cleivte H-Series Rod Bearings
 This Rotating Assembly is a good option for Forced Induction applications in the 900 - 1500 HP range. The Pistons supplied in this kit come standard with all available upgrades and are capable of handling 35lbs + of boost.

Compression Ratios are configured with a 57cc Chamber, 3.700" x .040" Head Gasket and .005" Piston to Deck clearance.

*Internal Balancing Available
   - Rods and Pistons weight matched to +/- 0.1g
   - Crankshaft Balanced to +/- 0.2g

We offer in-house balancing for all rotating assemblies and highly suggest having us balance the assembly for you. Normally these assemblies will require a slug of heavy metal installed into each end of the crankshaft due to the bobweight. Most shops will charge $75.00 per slug, installed. If you purchase the assembly and the balancing option at the same time, we waive the heavy metal fee.



Details

Categories

Shipping Information

  • Item Requires Shipping
  • 85.0 lbs.
  • W24.0000” x H24.0000” x L36.0000”
  • Free Shipping!
