K1 Technologies 011AN17593 - 4.6L / 5.0L Coyote H-Beam Connecting Rods

Comes with 7/16" ARP 2000 Rod Bolts - Strongest Modular 4.6L / 5.0L H-Beam Rods Available
Not Available
Pricing: $829.00


The New K1 Technologies Forged 4340 H-Beam Connecting Rods are the absolute strongest H-Beam Rods available for the Ford 4.6L and 5.0L Coyote Modular Engines. Unlike other H-Beams on the market, these K1 H-Beam Rods feature 7/16" ARP 2000 Rod Bolts. The 7/16" Rod Bolt makes these Rods much stronger than the other's available which only use a 3/8" Bolt. All K1 Technologies Connecting Rods are hand finshed and inspected in house at Wiseco / K1 Tech. This means consistent Big End and Pin End Bores for more consistent clearances. We highly recommend these connecting rods for anyone looking for a high quality, affordable H-Beam for applications up to 1200 HP.




Part Number  011AN17593
Application  Ford 4.6L / 5.0L Coyote
Length    5.933"
Big End Bore    2.239"
Wrist Pin  .866"
Big End Width   .940"
Pin End Width   .965
Rod Bolts  7/16" ARP 2000
Gram Weight   596g




  • K1T-011AN17593
  • K1T-011AN17593
  • K1 Technologies
  • New


Shipping Information

  • Item Requires Shipping
  • 15.0 lbs.
  • W8.0000” x H6.0000” x L12.0000”
  • Free Shipping!
