MHS 2V PI Stage 2 CNC Ported Head Package

Stage 2 CNC Ported 8 Thread Castings, MHS +1mm Stainless Steel Valves, MHS / PAC Stage 2 Valve Springs 4130 Chrome Moly Retainers, Bronze Valve Guides, Viton Valve Seals, CBN Surfacing, Brass Freeze Plugs, Assembly
Please Call for Availability


      Our Stage 2 CNC Ported Cylinder Heads are the best deal for 80% of applications. You get our Stage 2 CNC Porting Program w/ Hand Blended Bowls to Valve Seats, Our Stage 2 PAC Valve Springs, 4130 Chrome Moly Retainers, MHS Stainless Steel Valves, Tapered Nose Bronze Valve Guides, Trick Valve Job (4 Angle Intake, 3 Angle / Radius Exhaust), Viton Valve Stem Seals, Surfaced and Assembled.
The MHS Core Charge Options -
You can select to be responsible for sending in your cores prior to the completed heads shipping to you -or-
You can select to pay the $500 Core Charge & $50 Freight and the labels will ship with your completed Heads. You will then use those boxes to return the cores to MHS and receive a $500 refund once they are received.
  • 2004 and Newer Romeo 8 Thread Castings
  • Stage 2 CNC Porting Program / Hand Blended Bowls to Valve Seat
  • Bronze Valve Guides Installed
  • Performance Multi Angle Valve Job
  • MHS +1mm Stainless Steel Valves
  • Stage 2 PAC Valve Springs
  • MHS 4130 Chrome Moly Retainers
  • Viton Valve Seals
  • Brass Freeze Plugs
  • CBN Surfacing for MLS Gaskets
  • Assembly (Does not include Camshafts, Followers or Lash Adjusters)

Options and Upgrades:

  • Switch to Windsor Cores - This is needed for 99-00 4.6L and 5.4L applications.
    • These are late model 8 thread cores, with the larger timing cover bolt holes and Windsor Valve cover bolt pattern.
  • Upgrade to MHS Stage 3 PAC RPM Series Springs
    • Suggested for 18lbs of boost or more
  • Upgrade to Titanium Retainers
    • This is just personal preference. The 4130 Chrome Moly Retainers are just fine, but some people want Titanium and that's why there is an option.



Shipping Information

  • Item Requires Shipping
  • 40.0 lbs.
  • W24.0000” x H12.0000” x L12.0000”
  • Free Shipping!
