MHS 4V Stage 1 Cylinder Head Completion Package

MHS-4V-Completion-STG1
100% Bolt on Assembly
Pricing: $2,799.00

Customize Your Item

- Select Camshafts -
 * required
- Select Passenger Side Tensioner -
 * required
- Select Camshaft Bolts -
 * required
Qty:
Free Shipping!

Description

Modular Head Shop 4V Stage 1 Cylinder Head Completion Package

The 4V Completion Package is designed to take any of our 4V Cylinder Head Packages and make them a true, bolt on assembly. This package includes all the necessary components needed, plus our Camshaft Degree Service. The Cylinder Head Assemblies will arrive with the Camshaft Sprockets installed and set to their proper locations. The only thing you will need to do is bolt them on your short block and line up the Primary timing marks.

The Stage 1 Package includes all the basic OEM Timing Components with the exception of the secondary timing chains. Any time we upgrade the valve springs, we upgrade the secondary chains. While this may be overkill, we do not have secondary chain failures. This package is a good compliment to the Freshen Up or Stage 2 Package.

If there is one thing to upgrade I would suggest, it would be the passenger side secondary tensioner upgrade. Since the OEM one tensioners the wrong side of the chain, it will throw the camshaft timing off slightly. The fix is the Cobra Engineering Passenger Side Tensioner Body. This piece is machined from Billet Steel and uses the guts from the OEM Tensioner, but with the corrected geometry.

Stage 1 Package Includes:

  • MHS 4V Camshafts of Choice - Please choose from Drop Down
  • OEM Ford Lash Adjusters - Std 2V / 4V
  • OEM Ford Followers - Std 2V / 4V
  • OEM Ford Secondary Timing Chain Tensioners
  • Accufab Secondary Timing Chains
  • OEM Secondary Timing Chain Sprockets
  • OEM Ford Primary Timing Chain Sprockets
  • OEM Ford Camshaft Washers, Spacers and Bolts
  • Camshaft Degree Service
  • Full Professional Assembly

If you need help with camshaft selection, please contact us via Email. Modheadshop@gmail.com

Please note: This package in a completion package only, and does not include cylinder head cores, porting or any other work. This package is in addition to any of our Cylinder Head Porting Packages.

Details

  • MHS-4V-Completion-STG1
  • MHS-4V-Completion-STG1
  • Modular Head Shop
  • New

Categories

Shipping Information

  • Item Requires Shipping
  • 40.0 lbs.
  • W24.0000” x H12.0000” x L12.0000”
  • Free Shipping!
