Manley 14042-8 4.6L / 5.0L Coyote Forged 4340 H-Beam Connecting Rods

MAN-14042-8
Pricing: $599.99
Qty:

Description

  • Manufactured from 4340 forgings
  • Heat treated, stress relieved, shot peened and 100% magnafluxed
  • Weight matched sets +/- 1.5 grams

The Manley H-Beam is a popular choice of Connecting Rod with the 4.6L / 5.4L Modular Crowd. The became very well known when Ford used them in the 03-04 Cobra and then again in the Ford GT Super car. These Rods are fully machined, heat treated, stressrelieved, shot peened, and magnafluxed. These Rods come standard with 3/8" ARP 8740 Cap Screws.

Specifications



Part Number  14042-8
Application  Ford 4.6L / 5.0L Coyote
Length   5.933"
Big End Bore    2.239"
Wrist Pin Bore  .8671"
Big End Width   .940"
Pin End Width   .940"
Rod Bolts  3/8" ARP 8740
Gram Weight   615g
